Mini-Circuits, Inc. offers a wide range of plug-in, surface-mount and coaxial components kits to aid the engineer during the evaluation, design, and prototype stages; in addition, there are kits to provide components for the testing laboratory.
Each kit contains a carefully-selected group of models that will enable the largest versatility of usage by the engineer. As an example of Mini-Circuits quest to exceed our customer's expectations, these kits are priced up to 40 percent lower than the cost of individual units and are available
from stock. Click on the Kit Number for Specifications! Click on the price to buy!
Browse by Category
Amplifiers
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty |
| K1-ERA+ | ERA | DC to 8GHz Up to 13dBm Output Power |
Drop In | ERA-1+, -2+, -3+ | 10 | 30 |
| K2-ERA+ | ERA | DC to 4GHz Up to 18.4dBm Output Power |
Drop In | ERA-4+, -5+ | 10 | 20 |
| K1-ERASM+ | ERA-SM | DC to 8GHz 18.4dBm Output Power, Up to 13dBm Output Power, |
Mircro-X | ERA-1SM+, -2SM+, -3SM+ | 10 | 30 |
| K3-ERASM+ | ERA-SM | DC to 4GHz Up to 18.4dBm Output Power, |
Mircro-X | ERA-4SM+, -5SM+, 6SM+ | 10 | 30 |
| K3-Gali_GVA+ | GVA, GALI | DC to 8GHz Up to 21.5dBm Output Power, |
Mircro-X | GVA-84+, Gali-74+, -24+, -84+ | 10 | 40 |
| K4-Gali+ | GALI | DC to 8GHz Up to 18.2dBm Output Power, |
SOT-89 | Gali-1+, -21+, -2+, -33+, -3+, -4+, -5+, -51+, -6+ | 10 | 90 |
| K5-Gali+ | GALI | DC to 4GHz Up to 15.9dBm Output Power, |
SOT-89 | Gali-4F+, -5F+, -51F+, -55+, -6F+ | 10 | 50 |
| K1-GVA+ | GVA | DC to 7GHz Up to 21dBm Output Power, |
SOT-89 | GVA-81+, -82+, -83+, -84+ | 10 | 40 |
| K2-LEE+ | LEE | DC to 8GHz Up to 17.3dBm Output Power, |
Modified QFN | LEE-19+, -29+, -39+, -49+,-59+ | 10 | 50 |
| K-ZFL | ZFL | 2.5kHz to 2000MHz Up to 22dBm Output Power, |
Connectorized | ZHL-6A, ZFL-1000, ZFL-2000 | 1 | 3 |
| K1-PHA+ | PHA | 30 MHz to 8 GHz Up to 30 dBm Output Power |
SOT-89, MCLP 5x6mm | PHA-1+, -1H+, -83W+, -101+, -202+ | 5 | 25 |
Cables
| Model Number | Package | Description | Connector | Models Included in Kit | Qty. Ea. | Total Qty |
| KHFC2-086+ | 086 | DC-18GHz 2" to 12" Hand-Formable Interconnect Cables, 0.086" Diameter, SMA Male to SMA Male |
SMA Male to SMA Male | 086-2SM+, 086-3SM+, 086-4SM+, 086-5SM+, 086-6SM+, 086-7SM+, 086-8SM+, 086-9SM+, 086-10SM+, 086-12SM+ |
5 | 50 |
| KHFC3-086+ | 086 | DC-18GHz 3" to 24" Hand-Formable Interconnect Cables, 0.086" Diameter, SMA Male to SMA Male |
SMA Male to SMA Male | 086-3SM+, 086-6SM+, 086-12SM+, 086-18SM+, 086-24SM+ |
5 | 25 |
| KHFC2-141+ | 141 | DC-18 GHz 2" to 12" Hand-Formable Interconnect Cables, 0.141" Diameter, SMA Male to SMA Male |
SMA Male to SMA Male | 141-2SM+, 141-3SM+, 141-4SM+, 141-5SM+, 141-6SM+, 141-7SM+, 141-8SM+, 141-9SM+, 141-10SM+, 141-12SM+ |
5 | 50 |
| KHFC3-141+ | 141 | DC-18 GHz 3" to 24" Hand-Formable Interconnect Cables, 0.141" Diameter, SMA Male to SMA Male |
SMA Male to SMA Male | 141-3SM+, 141-6SM+, 141-12SM+, 141-18SM+, 141-24SM+ |
5 | 25 |
| KTFC1-FL47+ | 47 | DC-50 GHz 12" Flexible Interconnect Cables, 0.047" Diameter, Varying Connector Types |
2.92mm Male to 2.92mm Male, 2.4mm Male to 2.4mm Male, 2.92mm Male to 2.4mm Male , SMPM Female to SMPM Female, SMPM Female to 2.92mm Male, SMPM Female to 2.4mm Male | FL47-12KM+, FL47-12VM+, FL47-12KMVM+, FL47-12SSMP+, FL47-12SSMPKM+, FL47-12SSMPVM+ |
2 | 12 |
Directional Couplers
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K2-LTCC-WBZ+ | BLNK, BLJC, BLGE, CPJC | 2.4 to 2.5 GHz and 4.9 to 5.9 GHz LTCC Couplers and Baluns for WiFi Applications |
0402,0603,0805 | BLNK1-252R+, BLJC1-252R+, BLGE1-252R+, BLNK2-252R+, BLJC2-252R+, BLGE2-252R+, BLJC4-252R+, BLGE4-252R+, BLNK1-542R+, BLJC1-542R+, BLGE1-542R+, BLNK2-542R+, BLJC2-542R+, BLGE2-542R+, BLJC4-542R+, BLGE4-542R+, CPJC-6-252R+, CPJC-10-252R+, CPJC-17-252R+, CPJC-21-252R+, CPJC-28-252R+ | 5 | 105 |
| K1-DBTC+ | DBTC | 5 to 2000 MHz 9 to 20 dB Coupling |
Leadless SMT | DBTC-9-4+, -12-4+, -13-4+, -17-5+, -20-4+ | 5 | 25 |
| K2-DBTC+ | DBTC | 75 Ω 5 to 1500 MHz |
Leadless SMT | DBTC-10-4-75+, 13-5-75+, -16-5-75+, -18-4-75+, -9-4-75+, -12-4-75+ | 5 | 30 |
| K1-DCW+ | DCW | 1.2 to 7.2 GHz 6 to 30 dB Coupling |
0603 | DCW-6-722+, -11-722+, -6-352+, -14-472+, -22-332+, -9-432+, -30-272+ | 5 | 35 |
Equalizers
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K1-EQY24+ | EQY | DC to 20GHz 2-12 dB Gain Slopes, |
QFN | EQY-2-24+, -3-24+, -5-24+, -6-24+, -8-24+, -10-24+, -12-24+ | 5 | 35 |
| K1-EQY-24-DG+ | EQY | DC to 20GHz 2-12 dB Gain Slopes, |
DIE | EQY-2-24-DG+, -3-24-DG+, -5-24-DG+, -6-24-DG+, -8-24-DG+, -10-24-DG+, -12-24-DG+ | 5 | 35 |
| K1-EQY63+ | EQY | DC to 6GHz 1-10 dB Gain Slopes, |
QFN | EQY-1-63+, -2-63+, -3-63+, -4-63+, -5-63+, -6-63+, -8-63+, -10-63+ | 5 | 40 |
| K1-EQY-63-DG+ | EQY | DC to 6GHz 1-10 dB Gain Slopes, |
DIE | EQY-1-63-DG+, -2-63-DG+, -3-63-DG+, -4-63-DG+, -5-63-DG+, -6-63-DG+, -8-63-DG+, -10-63-DG+ | 5 | 40 |
| KVEQY-63+ | VEQY | DC to 6GHz 1-10dB Gain Slopes, |
SMA Connectorized |
VEQY-1-63+, -2-63+, -3-63+, -4-63+, -5-63+, -6-63+, -8-63+, -10-63+ | 1 | 8 |
| K1-EQY453+ | EQY | DC to 45GHz 3-10 dB Gain Slopes, |
QFN | EQY-3-453+, -4-453+, -5-453+, -6-453+, -7-453+, -8-453+, -9-453+, -10-453+ | 5 | 40 |
| K1-ZEQ24+ | ZEQ | DC to 20GHz 1-11dB Gain Slopes, |
2.92mm Connectorized |
ZEQ-1-24K+, -2-24K+, -4-24K+, -5-24K+, -7-24K+, -9-24K+, -11-24K+ | 1 | 7 |
Filters
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K-SCF+ | SCLP | DC to 420MHz Low Pass |
Leaded SMT | SCLF-21.4+, -30+, -45+, -135+, -190+, -380+, -420+ | 1 | 7 |
| K1-HFCN+ | HFCN | 710 to 7000 MHz High Pass |
1206 | HFCN-650+, -740+, -1200+, -1500+, -1760+, -2000+, -2275+, -2700+ | 5 | 40 |
| K2-HFCN+ | HFCN | 950 to 13000 MHz High Pass |
1206 | HFCN-880+, -1300+, -1320+, -1600+, -1810+, -1910+, -2100+, -3800+, -5500+, -8400+ | 5 | 50 |
| K1-LFCN+ | LFCN | DC to 630MHz Low Pass |
1206 | LFCN-225+, -320+, -400+, -490+, -530+, -575+, -630+ | 5 | 35 |
| K2-LFCN+ | LFCN | DC to 6700 MHz Low Pass |
1206 | LFCN-800+, -900+, -1000+, -1200+, -1325+, -1700+, -2000+, -2250+, -2400+, -5000+, -6000+, -6700+ | 5 | 60 |
| K3-LFCN+ | LFCN | DC to 630 MHz Low Pass |
1206 | LFCN-80+, -95+, -105+, -120+, -225+, -320+, -400+, -490+, -530+, -575+, -630+ | 5 | 55 |
| K4-LFCN+ | LFCN | DC to 6700MHz Low Pass |
1206 | LFCN-800+, -900+, -1000+, -1200+, -1325+, -1400+, -1450+, -1500+, -1525+, -1575+, -1700+, -1800+, -2000+, -2250+, -2400+, -5000+, -6000+, -6700+ | 5 | 90 |
| K5-LFCN+ | LFCN | DC to 6700MHz Low Pass |
1206 | LFCN-2000+, -2250+, -2400+, -2500+, -2600+, -2750+, -2850+, -3000+, -3800+, -4400+, -5000+, -6000+, -6700+ | 5 | 65 |
| K1-LFCW+ | LFCW | DC to 14 GHz LTCC Low Pass Filters |
0603 | LFCW-103+, LFCW-1062, LFCW-1142+, LFCW-123+, LFCW-133+, LFCW-143+, LFCW-272+, LFCW-5000+, LFCW-6000+, LFCW-8400+ | 10 | 100 |
| K1-LFCN-MMW+ | LFCN | DC to 30.5 GHz LTCC mm-Wave Low Pass Filters |
1206 | LFCN-2352+, LFCN-2752+, LFCN-2852+, LFCN-2952+, LFCN-3052+ | 10 | 50 |
| K1-HFCG+ | HFCG | 1400 to 18500 MHz LTCC High Pass Filters |
0805 | HFCG-1100+, HFCG-1500+, HFCG-1600+, HFCG-1760+, HFCG-2000+, HFCG-2100+, HFCG-2750+, HFCG-3000+, HFCG-3800+, HFCG-4400+ | 5 | 50 |
| K1-LFCG+ | LFCG | DC to 990 MHz LTCC Low Pass Filters |
0805 | LFCG-320+, LFCG-400+, LFCG-42+, LFCG-490+, LFCG-530+, LFCG-575+, LFCG-630+, LFCG-800+, LFCG-900+, LFCG-92+ | 5 | 50 |
| K2-LFCG+ | LFCG | DC to 2250 MHz LTCC Low Pass Filters |
0805 | LFCG-1000+, LFCG-1200+, LFCG-1325+, LFCG-1400+, LFCG-1525+, LFCG-1575+, LFCG-1700, LFCG-1800+, LFCG-2000+, LFCG-2250+ | 5 | 50 |
| K3-LFCG+ | LFCG | DC to 6100 MHz LTCC Low Pass Filters |
0805 | LFCG-2500+, LFCG-2600+, LFCG-2750+, LFCG-2850+, LFCG-3000+, LFCG-3400+, LFCG-3500+, LFCG-3800+, LFCG-4800+, LFCG-612+ | 5 | 50 |
| K1-BFCQ+ | BFCQ | 25 to 40 GHz LTCC Band Pass Filters |
1008 | BFCQ-2552+, BFCQ-2602+, BFCQ-2802+, BFCQ-3852A+ | 5 | 20 |
| K1-BBFCG | BBFCG | 2150 to 5700 MHz LTCC Band Pass Balun Filters |
0603 | BBFCG1-252+, BBFCG2-232+, BBFCG2-3275+, BBFCG2-352+, BBFCG2-362+, BBFCG2-3650+, BBFCG2-372+, BBFCG2-382+, BBFCG2-43+, BBFCG2-532+ | 5 | 50 |
| K1-HFCW+ | HFCW | 2400 to 21000 MHz LTCC High Pass Filters |
0603 | HFCW-1132+, HFCW-242+, HFCW-422+, HFCW-5000+ HFCW-5500+, HFCW-6010+, HFCW-7000+, HFCW-7500+, HFCW-9000+, HFCW-9500+ | 5 | 50 |
Fixed Attenuators / Terminations
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K2-BW1+ | BW | DC to 18GHz 2 Watts |
SMA Connectorized | BW-S3W2+, -S6W2+, -S10W2+ | 2 | 6 |
| K2-BW2+ | BW | DC to 18GHz 2 Watts |
SMA Connectorized | BW-S3W2+, -S6W2+, -S10W2+, -S20W2+, -S30W2+, -S40W2+ | 1 | 6 |
| K2-BW3+ | BW | DC to 18GHz 2 Watts |
SMA Connectorized | BW-S1W2+, -S2W2+, -S3W2+, -S4W2+, -S5W2+, -S6W2+, -S7W2+, -S8W2+, -S9W2+, -S10W2+ | 1 | 10 |
| K5-BW1+ | BW | DC to 18GHz 5 Watts |
SMA Connectorized | BW-S1W5+, -S2W5+, -S3W5+, -S4W5+, -S5W5+, -S6W5+, -S8W5+, -S10W5+ | 1 | 8 |
| K5-BW2+ | BW | DC to 18GHz 5 Watts, |
SMA Connectorized | BW-S3W5+, BW-S6W5+ | 1 | 4 |
| BW-S10W5+ | 2 | |||||
| K5N-BW3+ | BW | DC to 18GHz 5 Watts |
N Connectorized | BW-N3W5+, BW-N6W5+ | 1 | 4 |
| BW-N10W5+ | 2 | |||||
| K1-GAT+ | GAT | DC to 8 GHz 0.5 Watts |
Modified QFN | GAT-2+,-3+,-4+,-6+,-8+,-10+,-15+,-20+,-30+ | 5 | 45 |
| K2-GAT+ | GAT | DC to 8 GHz 0.5 Watts |
Modified QFN | GAT-3+,-6+,-10+,-15+,-20+ | 5 | 25 |
| K3-GAT+ | GAT | DC to 8 GHz 0.5 Watts |
Modified QFN | GAT-0+,-1+,-2+-3+,-4+,-5+,-6+,-7+,-8+,-9+,-10+,-12+,-15+,-20+,-30+ | 5 | 75 |
| K1-HAT+ | HAT | DC to 2GHz 1 Watts |
BNC Connectorized | HAT-3+, -6+, -10+, -20+, -30+ | 1 | 5 |
| K2-HAT+ | HAT | DC to 2GHz 1 Watts |
BNC Connectorized | HAT-1+, -2+, -3+, -4+, -5+, -6+, -7+, -8+, -9+, -10+ | 1 | 10 |
| K1-KAT+ | KAT | DC to 43.5GHz 2 Watts |
QFN | KAT-3+, -6+, -10+, -15+, -20+ | 10 | 50 |
| K2-KAT+ | KAT | DC to 43.5GHz 2 Watts |
QFN | KAT-0+, -1+, -2+, -3+, -4+, -5+, -6+, -7+, -8+, -9+, -10+, -12+, -15+, -20+, -30+ | 5 | 75 |
| K2-KAT-DG+ | KAT | DC to 50GHz 2 Watts, |
DIE | KAT-0+, -1+, -2+, -3+, -4+, -5+, -6+, -7+, -8+, -9+, -10+, -12+, -15+, -20+, -30+ | 5 | 75 |
| K1-LAT+ | LAT | DC to 2.5GHz 0.5 Watts |
Leaded SMT | LAT-3+, -6+, -10+, -15+, -20+ | 4 | 36 |
| LAT-1+, -2+, -4+, -5+, -7+, -8+, -9+, -12+ | 2 | |||||
| K1-PAT+ | GAT | DC to 7GHz 1 Watts |
QFN | PAT-3+, -6+, -10+, -15+, -20+ | 4 | 20 |
| K2-PAT+ | GAT | DC to 7GHz 1 Watts |
QFN | PAT-0+,-1+,-2+,-3+,-4+,-5+,-6+,-7+,-8+,-9+,-10+,-12+,-15+,-20+,-30+ | 5 | 75 |
| K1-RCAT+ | RCAT | DC to 20GHz 2 Watts |
QFN | RCAT-00+, -03+, -06+, -10+, -15+, -20+ | 10 | 60 |
| K1-VAT+ | VAT | DC to 6GHz 1 Watts |
SMA Connectorized | VAT-3+, -6+, -10+, -20+, -30+ | 1 | 5 |
| K2-VAT+ | VAT | DC to 6GHz 1 Watts |
SMA Connectorized | VAT-1+, -2+, -3+, -4+, -5+, -6+, -7+, -8+, -9+, -10+ | 1 | 10 |
| K3-VAT+ | VAT | DC to 6GHz 1 Watts |
SMA Connectorized | VAT-3+, -6+, -10+ | 2 | 6 |
| K1-VAT2+ | VAT | DC to 6GHz 2 Watts |
SMA Connectorized | VAT-3W2+, -6W2+, -10W2+, -20W2+, -30W2+ | 1 | 5 |
| K2-VAT2+ | VAT | DC to 6GHz 2 Watts |
SMA Connectorized | VAT-1W2+, -2W2+, -3W2+, -4W2+, -5W2+, -6W2+, -7W2+, -8W2+, -9W2+, -10W2+ | 1 | 10 |
| K3-VAT2+ | VAT | DC to 6GHz 2 Watts |
SMA Connectorized | VAT-3W2+, -6W2+, -10W2+ | 2 | 6 |
| K4-VAT2+ | VAT | DC to 6GHz 2 Watts |
SMA Connectorized | VAT-3W2+, -6W2+, -10W2+, -20W2+ | 1 | 4 |
| K1-UNAT+ | UNAT | DC to 6GHz 0.5 and 1 Watts |
N Connectorized | UNAT-3+, -6+, -10+, -15+, -20+ | 2 | 10 |
| K2-UNAT+ | UNAT | DC to 6GHz 0.5 and 1 Watts |
N Connectorized | UNAT-1+, -2+, -3+, -4+, -5+, -6+, -7+, -8+, -9+, -10+, -15+, -20+, -30+ | 1 | 13 |
| K1-QAT+ | QAT | DC to 50 GHz Up to 2 Watts |
QFN | QAT-0+, -1+, -2+, -3+, -4+, -5+, -6+, -7+, -8+, -9+, -10+, -12+, -15+, -20+, -30+ | 5 | 75 |
| K1-YAT-A+ | YAT-A | DC to 18 GHz Up to 2 Watts |
QFN | YAT-3A+, -6A+, -10A+, -15A+, -20A+ | 5 | 50 |
| K2-YAT-A+ | YAT-A | DC to 18 GHz Up to 2 Watts |
QFN | YAT-0A+, -1A+, -2A+, -3A+, -4A+, -5A+, -6A+, -7A+, -8A+, -9A+, -10A+, -12A+, -15A+, -20A+, -30A+ | 10 | 150 |
| K1-VAT-A+ | VAT | DC to 6GHz Up to 2 Watts |
SMA Connectorized | VAT-3A+, -6A+, -10A+, -20A+, -30A+ | 1 | 5 |
| K2-VAT-A+ | VAT | DC to 6GHz Up to 2 Watts |
SMA Connectorized | VAT-1A+, -2A+, -3A+, -4A+, -5A+, -6A+, -7A+, -8A+, -9A+, -10A+ | 1 | 10 |
| K3-VAT-A+ | VAT | DC to 6GHz Up to 2 Watts |
SMA Connectorized | VAT-3A+, -6A+, -10A+ | 2 | 6 |
| K1-UNAT-A+ | UNAT | DC to 6GHz Up to 2 Watts |
N Connectorized | UNAT-3A+, -6A+, -10A+, -15A+, -20A+ | 2 | 10 |
| K2-UNAT-A+ | UNAT | DC to 6GHz 1 to 2 Watts, Attenuator Level Dependent |
N Connectorized | UNAT-1A+, -2A+, -3A+, -4A+, -5A+, -6A+, -7A+, -8A+, -9A+, -10A+, -15A+, -20A+, -30A+ | 1 | 13 |
| K1-HAT-A+ | HAT | DC to 2GHz 0.8 to 2 Watts |
BNC Connectorized | HAT-3A+, -6A+, -10A+, -20A+, -30A+ | 1 | 5 |
| K2-HAT-A+ | HAT | DC to 2GHz 1.1 to 2 Watts |
BNC Connectorized | HAT-1A+, -2A+, -3A+, -4A+, -5A+, -6A+, -7A+, -8A+, -9A+, -10A+ | 1 | 10 |
Frequency Mixers
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K1-ADE+ | ADE | 2 to 4000 MHz 3 to 17 dBm LO Powers |
Leaded SMT | ADE-1L+, -2+, -18W+, -30W+, -35MH+, -17H+ ADEX-10L+, -10H+ |
5 | 40 |
| K1-MCA+ | MCA | 500 to 5000 MHz 10, 13, and 17 dBm LO Powers |
Leaded SMT | MCA-35H+, -35LH+, -35MH+, -50H+, -50LH+, -50MH+ | 5 | 30 |
| K2-MCA+ | MCA | 1760 to 3600 MHz 10, 13, and 17 dBm LO Powers |
Leaded SMT | MCA-19FH+, -19FLH+, -19FMH+, -30FH+, -30FLH+, -30FMH+, -36FH+, -36FLH+, -36FMH+ | 2 | 18 |
| K1-MCA1+ | MCA1 | 300 to 1200 MHz 4 to 17 dBm LO Powers |
Leaded SMT | MCA1-12GL+, -24+, -24LH+, -42MH+, -42+, -60+, -60LH+, -80H+, -85L+, -113H+ | 5 | 50 |
| K1-SIM+ | SIM | 750 to 15000 MHz 4, 7, and 10 dBm LO Powers |
Leadedless SMT | SIM-14+, -43+, -63LH+, -73L+, -83+, -83LH+, -153+, -153LH+ | 5 | 40 |
| K1-ZX05+ | ZX05 | 5 to 15000 MHz, 7 dBm LO Power |
SMA Connectorized | ZX05-5+, -43+, -153+ | 1 | 3 |
| K2-ZX05+ | ZX05 | 0.5 to 15000 MHz 10 and 13dBm LO Powers |
SMA Connectorized | ZX05-1MHW+, -12MH+, -63LH+, -153MH+ | 1 | 4 |
| K3-ZX05+ | ZX05 | 5 to 10000 MHz 17 dBm LO Power |
SMA Connectorized | ZX05-1HW+, -17H+, -43H+, -14H+ | 1 | 4 |
| K1-MDB+ | MDB | 2.2 to 50 GHz 15 dBm LO Power |
Leaded SMT | MDB-24H+, MDB-44H+, MDB-54H+, MDB-73H+ | 5 | 20 |
Phase Detectors
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K-PD | MPD, SYPD | 1 to 400 MHz | Plug-In, Leadless SMT | MPD-1+, MPD-2+, MPD-21+, SYPD-1+, SYPD-2+ | 1 | 5 |
Power Splitters
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K1-ADP+ | ADP | 0.5 to 2000 MHz 2-Way 0° |
Leaded SMT | ADP-2-1+, -2-1W+, -2-9+, -2-10+, -2-4+, -2-20+ | 2 | 12 |
| K1-QCN+ | QCN | 220 to 4500 MHz 2-Way 90° |
1206 | QCN-3+, -5+, -7+, -12+, -12A+, -19+, -25+, -27+, -34+, -45+ | 2 | 20 |
| K1-SBTC+ | SBTC | 5 to 2500 MHz 2-Way 0° |
Leaded SMT | SBTC-2-10+, -2-20+, -2-25+ | 5 | 15 |
| K1-ZX10+ | ZX10 | 2 to 12600 MHz 2-Way 0° |
SMA Connectorized | ZX10-2-12+, -2-20+, -2-25+, -2-42+, -2-71+, -2-98+, -2-126+ Free deluxe wood storage case |
1 | 7 |
| K1-SCG+ | SCG | 900 to 5900 MHz LTCC, 2-Way, 3-Way, 0° |
0805 | SCG-2-242+, SCG-2-322+, SCG-2-422+, SCG-2-592+, SCG-3-162+, SCG-3-262+, SCG-3-592+ | 7 | 35 |
RF Transformers
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K2-LTCC-WBZ+ | BLNK, BLJC, BLGE, CPJC | 2.4 to 2.5 GHz and 4.9 to 5.9 GHz LTCC Couplers and Baluns for WiFi Applications |
0402,0603,0805 | BLNK1-252R+, BLJC1-252R+, BLGE1-252R+, BLNK2-252R+, BLJC2-252R+, BLGE2-252R+, BLJC4-252R+, BLGE4-252R+, BLNK1-542R+, BLJC1-542R+, BLGE1-542R+, BLNK2-542R+, BLJC2-542R+, BLGE2-542R+, BLJC4-542R+, BLGE4-542R+, CPJC-6-252R+, CPJC-10-252R+, CPJC-17-252R+, CPJC-21-252R+, CPJC-28-252R+ | 5 | 105 |
| K-ADT-1+ | ADT | 0.15 to 775MHz Impedance Ratios from 1:1 to 1:9, 50Ω |
Leaded SMT | ADT1-1+, ADT2-1T+, ADT3-1T+, ADT4-1WT+, ADT9-1T+ | 2 | 10 |
| K1-ADTL+ | ADTL | 0.5 to 1800MHz Impedance Ratios of 1:1 and 1:2 50Ω and 75Ω Models |
Leaded SMT | ADTL1-12+, -18-75+, -4-75+, -15-75+, -18+ | 10 | 50 |
| K1-TCG2+ | TCG | 0.3 to 3000MHz Impedance Ratios from 1:9 to 16:1 50Ω and 75Ω Models |
Leaded SMT | TC1-1TG2+, TC1-1G2+, TC1-1-13MG2+, TC1-15G2+, TC1.5-1G2+, TC2-1TG2+, TC3-1TG2+, TC4-1TG2+, TC4-1WG2+, TC4-14G2+, TC8-1G2+, TC9-1G2+, TC16-1TG2+, TC4-11G2+, TC9-1-75G2+ | 10 | 150 |
| K1-TCM+ | TCM | 0.5 to 2500MHz Impedance Ratios from 1:1 to 9:1 Transformers |
Leaded SMT | TCM1-1+, TCML1-11+, TCML1-19+, TCM2-1T+, TCM3-1T+, TCM4-1W+, TCM4-14+, TCM4-6T+, TTCM4-4+, TCM4-19+, TCM4-25+, TCM8-1+, TCM9-1+ | 10 | 130 |
| K1-TCN+ | TCN | 600 to 2600MHz Impedance Ratios from 1:1 to 4:1 LTCC Construction |
1206 | TCN1-10+, TCN1-23+, TCN2-14+, TCN2-26+, TCN3-11+, TCN4-13+, TCN4-22+ | 5 | 35 |
| K1-NCS+ | NCS | 223 to 8000 MHz Impedance Ratios of 1:1, 1:1.5: 1:2, 1:3, and 1:4 50Ω |
0805 | NCS1-23+, NCS1-292+, NCS1-332+, NCS1-422+, NCS1-521+, NCS1-63+, NCS1.5-232+, NCS2-222+, NCS2-232+, NCS2-282+, NCS2-33+, NCS2-392+, NCS2-592+, NCS2-62+, NCS2-622+, NCS2-771+, NCS2-83+, NCS3-272+, NCS3-72+, NCS4-102+, NCS4-232+, NCS4-272+, NCS4-442+, NCS4-521+, NCS4-63+ | 5 | 125 |
| K1-TCW+ | TCW | 700 to 7125 MHz Impedance Ratios from 1:1, 1:2, and 1:4 50Ω |
0603 | TCW1-2700+, TCW1-272+, TCW1-33+, TCW1-3901+, TCW1-392+, TCW1-6000+, TCW2-272+, TCW2-282+, TCW2-392+, TCW2-6000+, TCW2-63+, TCW2-722+, TCW4-262+, TCW4-582+ | 10 | 140 |
| K1-TRAN-HP+ | SYTX | 10 to 1000 MHz Impedance Ratios from 1:2 to 4:1 50Ω |
Leadless SMT | SYTX2-61HP+, SYTX1-52HP-15W+, SYTX2-451-5W+, SYTX2-52HP-20W+, SYTX4-13HP+ | 5 | 25 |
RF Transistors
| Model Number | Model Series | Description | Package | Models Included in Kit | Qty. Ea. | Total Qty. |
| K1-SAV_TAV+ | SAV, TAV | 0.01 to 10 GHz Up to 20 dBm Output Power |
MCLP 1.42x1.18mm, MCLP 3x3mm, SOT-343 |
SAV-331+, SAV-541+, SAV-551+, SAV-581+, TAV-541+, TAV-551+, TAV-581+, TAV1-331+, TAV1-541+, TAV2-14LN+ | 10 | 100 |
Top
