DOCSIS CATV Product Selection Guide

Actives and Passives from DOCSIS 1.x to 4.x and Beyond

With an extensive portfolio of active and passive components for CATV and HFC systems and equipment, Mini-Circuits offers complete solutions as operators upgrade network infrastructure for DOCSIS® 4.0 and beyond.

Image 2

Filter Solutions Product Guide

Desinged and Built In-House By Mini-Circuits

Mini-Circuits has over 3000 catalog models of RF filters available plus custom designs, including low-pass, high-pass, band-pass, band-stop, diplexers, triplexers, and more. Check out this product guide to find the right filter for your application.
Image 2

High Frequency Solutions

Amplifiers & Modules for mmWave Applications up to 110 GHz

Mini-Circuits’ high-frequency amplifiers are ideal for extending power and dynamic range in millimeter wave test setups from Ka-band through W-band. All models feature extensive built-in protections and wide DC voltage range for high reliability and ease of use. Our flexible design platform and in-house production capability also enables fast, affordable customizations for your special requirements.
Image 2

LTCC Innovations Product Line Overview

Industry-Leading Design Capability

LTCC devices are fabricated with capacitors, inductors and distributed structures embedded in multi-layered ceramic substrate and sintered into a single monolithic component. LTCC passives have become a mainstay component technology due to their unique combination of performance, tiny footprint, reliability and cost-effectiveness.

Our design team has the most advanced knowledge of LTCC materials, design methods and fabrication processes in the industry, building on 20+ years of R&D and multiple active patents to deliver unprecedented capabilities for customer designs.
Image 2

MMIC Product Selection Guide

Hundreds of In-House Designs from DC to mmWave

Mini-Circuits’ industry-leading line of MMIC devices is built on over 20 years of R&D and production experience across our global operating footprint. Our portfolio comprises an extensive selection of active and passive devices designed, packaged and characterized in-house with tight process control under stringent quality and reliability standards.

We maintain strong partnerships with some of the world’s leading foundries to leverage pHEMT, HBT and IPD fabrication processes on GaAs and GaN substrates to deliver the best combination of performance parameters in every design to meet your system requirements.
Image 2

Power Sensors Guide

Turn Your PC into a High Performance Power Meter

Discover Mini-Circuits’ versatile PWR line of smart power sensors, designed to cater to diverse test needs, budgets, and skill levels. The lineup features a variety of models supporting frequencies up to 40 GHz, and accommodating various signal types from continuous wave/single tone setups to pulsed signals and contemporary digital modulations. With input power capabilities down to -60 dBm, these sensors are perfect for analyzing transmitted signals and assessing components with significant loss or rejection, like filters. Offering sample rates of up to 80 million samples per second, these sensors enable precise signal analysis with exceptional measurement accuracy.
Image 2

Space Applications Product Selection & Services Guide

30+ Years of In-House Launch Prep

Mini-Circuits has a long history of space-level screening and testing servicing some of the earliest government space missions all the way through to the modern independent enterprises. Most of our catalog and custom components can be upscreened in-house for Mil Standard or equivalent in as little as 90 days. Our in-house screening reduces costs and accelerates your project timeline.
Image 2

ISM RF Energy Solutions

Building-Block Modules & Turnkey Systems

Mini-Circuits' RF & microwave energy portfolio covers all the key functions in your system block diagram from signal source and control to amplification and more. Choose from our selection of building-block modules to design your own system, or put our in-house design & manufacturing experience to work for you with a turnkey solution.
Image 2

RF & Microwave Test Accessories Product Line Overview

One Stop Shopping from R&D to Production - DC to 110 GHz

Mini-Circuits is your one stop shop for all your essential RF test lab tools and accessories up to 110 GHz. From cables and adapters to passive components, amplifiers and more, we offer everything you need to stock your lab off the shelf, ready for immediate shipment. Check out the range of our selection in this product line overview.
Image 2

Test Solutions Product Line Overview & Guide

The Mini-Circuits Difference - Flexible, Reliable, Affordable & Fast

Mini-Circuits has successfully helped hundreds of customers improve efficiency and reduce cost in their test operations. The information in this complete product line overview and selection guide is full of solutions to help you do the same from signal routing and distribution to signal conditioning, measurement and more.
